- 12/6/3-ch záznam
- 110 mm šírka papiera
- 12/6/4/3/1-ch display
- 7” farebný LCD dotykový display
- kompletný záznam : max 10 min.
- dátový formát : HL7, XML, SCP, PDF
- zálohovanie dát : Interná SD karta / externé USB
- prenos dát : USB(RS232), Ethernet LAN,
- bluetooth
- externé zariadenie I/F Externá tlačiareň / Barcode and Card reader
- stresové EKG I/F
- aktualizácia cez USB
- výklopný LCD display
- certifikované podľa normy IEC60601-1
Technická špecifikácia
| Recording ECG Leads | 12 standard leads: I, II, III, aVR, aVL, aVF , V1, V2, V3, V4, V5, V6 | ||
| Lead Group | Standard / Cabrera / User defined combination | ||
| Recording Mode | Auto / Manual / Copy / Elapsed / Rhythm / Calibration | ||
| Recording Channel | 12 / 6+1 / 3+1 ch 1-ch (lead II) / 2-ch(Lead II,V5) / 3-ch (Lead I, II, V5) rhythm record |
||
| Displaying Channel | 12 / 6 / 4 / 3 / 2 / 1 ch. | ||
| Sensitivity (mm/mV) | 2.5, 5, 10, 20, [40, Auto (option)] | ||
| Type | 406NH | Non-interpretive | |
| 406RH | 406NH + Interpretive | ||
| 406RSH | 406RH + Stress ECG interface | ||
| Recording Speed(mm/sec) | Auto | 5,10, 12.5, 25, 50, [100 (option)] | |
| Manual | 25, 50 | ||
| Recording System | High resolution(Vertical/ Horizotal203/508dpi) thermal head printer with 8 dots/mm | ||
| Recording paper | 110 mm x 30 m thermal sensitive roll type 110 mm x 60 m thermal sensitive z-folder type(option) |
||
| Recording length(auto) | User selected length (5 ~ 25 sec ) | ||
| ECG Data acquisition | Simultaneous 12-lead ECG | ||
| Elapsed Rhythm Record | Latest 5 ~ 10 sec signal record | ||
| Full Disclosure Report | User selected a lead signal and record compact rhythm for 1 min. | ||
| Patient Data Input | Alphanumeric key with touch screen key pad | ||
| Language | English, Spanish, Russian, Turkish | ||
| Frequency Response | Unfiltered 0.05 ~ 200 Hz (-3dB) | ||
| Digital filter | Baseline drift (0.05 / 0.5Hz) Muscle (25 / 35Hz) and AC (50 / 60 Hz) High frequency noise filter (75 / 100 / 150 / 200 Hz) |
||
| Calibration Test (1 mV) | Frequency response and sensitivity test using internal 1 mV signal | ||
| Auto Power Switch off | After 5. 10, 15 minutes inactive operation | ||
| Power Requirements | AC | AC 100~240V±10 %, ~50 / 60 Hz (Fully charged 2hrs record) | |
| DC | Built-in rechargeable battery ( NiMH, +19.2V, 2200mAh) | ||
| A/D Conversion | 120 bits | ||
| Sampling Rate | 500 Hz | Input Unit : 8,000 Samples/s | ||
| Input Impedance | Greater than 100 MΩ | ||
| CMRR | Greater than 100dB | ||
| Detection Parameter | Pace maker detection (Option) / Variable R-R detection / Real timeheart rate | ||
| Alarm | Paper empty / Lead-off / Low battery level | ||
| Performance | AAMI requirements | ||
| Safety | Class I (Degree of protection against electric shock: Defibrillation-proof type CF applied parts) IEC60601-1 /IEC60601-2-25 |
||
| Patient Leakage Current | Less than 10 ㎂ | ||
| Digital Interface Port | 2 USB-RS232, Ethernet LAN(optional) Wireless-Biuetooth(Option) | ||
| PC Connection | PC Data Management with TRISMED PC Net S/W (option) Stress ECG interface with TRISMED Stress ECG S/W (option) |
||
| External printer | USB connection (Inkjet / Laser printer) | ||
| Memory | Internal SD card to save up to 2500 patients data (10 sec data) External USB memory stick |
||
| Display LCD | 7” Color, 800x480dots, Viewing area:152.40mm x91.44 mm | ||
| Key Operation | Alphanumeric Membrane Hard Key and Touch Screen | ||
| Dimension | 313 x 252 x 85 mm | ||
| Weight | 2.5 Kg Without Bettery | ||
| Temperature | Operating ( 10 ~ 40 ℃) Storage (-20 ~ 60 ℃) | ||
| Relative humidity | Operating ( 10 ~ 80 %) Storage (10 ~ 90 %) | ||
| Atmosphere pressure | 50~ 106 kPa | ||
